Mascord House Plan 21136: The Chorley

The Chorley

Plan 21136

  • 1699 SqFt
  • 3 Beds
  • 2 Baths
  • 1 Pwdr
  • 2 Floors
  • 2 Car Garage

Photos

Photographed Homes May Include Modifications Not Reflected in the Design

Home Details

Heated Space

  • Upper Floor

    998 SqFt
  • Main Floor

    701 SqFt
  • Total Area

    1699 SqFt

Beds and Baths

  • Bedrooms

    3
  • Full Baths

    2
  • Half Baths

    1
  • Floors

    2

Exterior Dimensions

Garage

  • Garage Bays

    2 Car Garage
  • Garage Area

    423 SqFt
  • Garage Location

    Front
  • Garage Orientation

    Straight-On

Structure

  • Roof Framing

    Truss
  • Roof Material

    Shake/Comp Roof
  • Snowload

    25 lb/sf
  • Wall Framing

    2 x 6
  • Main Roof Pitch

    9/12

A Walk Through The Chorley

For so many of us, the dream is a quiet life with the family somewhere on a secluded shoreline. The Chorley can help you realize that dream. Imagine sitting out on the back patio, listening to the wind whispering through the trees around your home as waves break against the rocky shore. You’ll find that this is a versatile area — host a barbecue or spend some time reading, and enjoying the peaceful atmosphere.

Inside, the wide open living space gives you an expansive, yet relaxing feeling. On wintry nights, you’ll have hours of quality time with your family. Watch TV or play board games in the great room as Christmas decorations twinkle in the windows. When dinner time rolls around, there’s plenty of room for the whole family to gather in the enormous wrap-around kitchen. The kids can do their homework at the kitchen island or on the dining area’s built-in desk while you prepare something hearty — perhaps steaming bowls of clam chowder with biscuits and a fresh green salad.

The Chorley’s second story gives you so many amenities within a space-saving design. At the top of the steps, you’ll find a desk area that comes with several uses. Use it as a small home office or as a study, or let the kids have this space for school projects. There are also two spacious bedrooms, giving your children plenty of room for toys, sleepovers, and more.

The back half of the upper story is devoted to a luxurious master suite. As you walk through the master bedroom’s double doors, you’ll be treated to the sight of the ocean through this room’s picture windows. On warm summer evenings, you’ll want to open these windows to let in the cool ocean breeze as you drift off to sleep.

Just off the master bedroom, you’ll find the master bathroom, an enormous walk-in closet and the Chorley’s laundry area. With the laundry area conveniently situated close to your home’s major sources of laundry — the bedrooms and the bathrooms — you’ll spend far less time hauling baskets of laundry around the house. And, with the walk-in closet just off the master bathroom, you’ll be able to streamline your morning routine, which will make your already carefree lifestyle even easier. When it comes to the master bathroom, you’ll not only have a roomy tub for soaking and a beautiful tiled shower, but also his-and-hers sinks for both you and your partner.
