Mascord House Plan 21134: The Barnoldswick
The Barnoldswick

Plan 21134

Mascord House Plan 21134: The Barnoldswick

Rear Rendering

Plan 21134 - The Barnoldswick - Craftsman Style and Modern Design Come Together

Main Floor Plan

Main Floor Plan image for Mascord Barnoldswick-Craftsman Style and Modern Design Come Together-Main Floor Plan

Upper Floor Plan

Upper Floor Plan image for Mascord Barnoldswick-Craftsman Style and Modern Design Come Together-Upper Floor Plan

A Walk Through The Barnoldswick

The Barnoldswick is a rare home that encompasses both traditional Craftsman and modern design themes. Choose a beautifully forested area to build, and you’ll spend endless hours admiring the view through impeccably designed windows and outdoor spaces — particularly the rear patio, which is partly shaded by an elegant attached pergola. This home’s bold front facade — with a recessed porch, traditional Craftsman ornamentation and tall upper story windows — is nothing short of impressive.

And that’s just the beginning. Walk through the front door, down the hall and into the wide open living space. To your right, you’ll find a smart corner kitchen, while the rest of the room is devoted to living and dining space. This kitchen’s design lets you make breakfasts, lunches and dinners in full view of your family and your beautiful outdoor spaces. In addition, the pantry and refrigerator are only a few steps away from the garage, which means you can unload groceries quickly and easily on shopping day.

To truly enjoy this home’s great room, you’ll need to experience it in every season. Throughout the fall and winter, make sure to spend time warming up by the fireplace as you enjoy the sights of the colorful forest or the falling snow. Come spring and summer, you’ll delight in the fresh, verdant view behind your home and in the dappled sunlight filtering into this room through the attached pergola outside.

Your entire family will find the Barnoldwick’s upper floor a delightful, restful place to be. At the top of the stairs are the two bedrooms. Each of these rooms features beautiful windows, plenty of closet space for toys and clothes and a shared bathroom. Just off the shared bathroom is a convenient laundry and utility room, which helps you streamline busy laundry days.

The other end of this floor is devoted entirely to an elegant master suite. Two tall windows flank the bed, while smaller windows above the bed let sunlight filter gently into the room. You’ll find that this room is spacious enough to feature dressers and even your own private sitting area for those times when you’d like to escape to a peaceful private place. In addition, the master suite comes with not one, but two walk-in closets and a private master bathroom with a beautiful tiled shower.

Build this home to raise a family or build it as your vacation home. Either way, the Barnoldswick has everything you need to enjoy a rich, full life.

Home Details

Heated Space

  • Upper Floor

    1041 SqFt
  • Main Floor

    718 SqFt
  • Total Area

    1759 SqFt

Beds and Baths

  • Bedrooms

    3
  • Full Baths

    2
  • Half Baths

    1
  • Floors

    2

Exterior Dimensions

Garage

  • Garage Bays

    1 Car Garage
  • Garage Area

    295 SqFt
  • Garage Location

    Front
  • Garage Orientation

    Straight-On

Structure

  • Roof Framing

    Truss
  • Roof Material

    Shake/Comp Roof
  • Snowload

    25 lb/sf
  • Wall Framing

    2 x 6
  • Main Roof Pitch

    12/12

Cottage

This home is typical of the cottage style. In modern usage, a cottage is usually a modest, often cozy dwelling, typically in a rural or semi-rural location. However there are cottage-style dwellings in cities, and in places such as Canada the term exists with no connotations of size at all (cf. vicarage or hermitage). In the United Kingdom the term cottage also tends to denote rural dwellings of traditional build, although it can also be applied to dwellings of modern construction which are designed to resemble traditional ones ("mock cottages").

Craftsman

The Mascord collection of craftsman house plans highlight features that were first introduced with the Arts and Crafts movement, which thrived from 1876-1915, and continues to be celebrated today. These homes have great curb appeal, lots of detail and the amenities you need for modern living. Check out the collection for more great home designs.

Vacation

This plan has been chosen as part of our vacation home collection. Vacation homes generally have central, open living spaces and offer a great connection to the outdoors, perhaps including an outdoor kitchen or BBQ area. Some homes will have just a few bedrooms, creating a cozy private get-away for your family. Other homes will feature many bedrooms, designed fords family get-togethers at the coast or in the mountains - a place you can invite friends and family to join you in outdoor fun.

Choose Plan Set

Foundations

View In-Ground Basement Details

Additional Options

High-Res Mktg Images $30

Are you selling a home constructed from these plans? License the renderings and marketing floor plan images for use on MLS, on flyers or on your website. (Note: we don't offer photography licensing)
